The electronic module is an assembly containing several power components, mostly power semiconductor devices, properly internally interconnected to perform a power conversion function. These modules are the basic requirement of every user who wants to build their own projects. It includes breakout boards, voltage regulator, relay, display, led module and more.
-
650nm 6mm 50mW 5V Red Laser Diode
- Output Power: 50mW.
- Working Voltage: 5V DC.
- Operating current: <30mA.
- Housing material: Copper.
- Laser beam Size: <φ8mm ( @15 m )
- Working temperature: -10C ~ 40C
- Laser wavelength: 650nm red-colored.
- Working life: more than 2000 hours.
- Spot mode: Dot Facula (continuous output).
- Power lead length: 80mm.
₹49.00 Excl. GST 18% -
650nm 6mm 5mW 5V Red Laser Diode
- Output Power: 5mW.
- Working Voltage: 3V to 5V DC.
- Operating current: <40mA.
- Housing material: Copper.
- Laser beam Size: <φ8mm ( @15 m )
- Working temperature: -10°C ~ 40°C
- Laser wavelength: 650nm red-colored.
- Working life: more than 2000 hours.
- Spot mode: Dot Facula (continuous output).
- Power lead length: 80mm.
₹49.00 Excl. GST 18% -
8 Channel 12V Relay Module with Optocoupler
- Operating Voltage: 12V DC
- Equipped with high-current relay 10A 250VAC / 10A 30VDC
- It can control both AC and DC appliances such as Solenoids, Motors, lights, fans, etc.
- High-quality screw terminals (Terminal Block) provided (C, NC, NO) for quick and easy connection.
- Freewheeling diode to protect your microcontroller.
- Input Signal Pin connected to Burg stick for easy accessibility.
- LED Status indicators to indicate the relay ON/OFF status.
- Mounting holes provided.
₹370.00 Excl. GST 18% -
8 Channel 5V Relay Module
- The 8550 transistor drive, driveability.
- Relay control interface by single-chip IO.
- Low-level suction close, high-level release.
- Easy to use, simple 3 line structure.
- A fixed bolt holes for easy installation.
- It has a relay status indicator led Power LED(Green), 8 relay status indicator LED(Red)
₹360.00 Excl. GST 18% -
AVR ISP 10 Pin to 6 Pin Adapter Board
- Made of high-quality material, practical and durable
- No. of Pinon USBASP side: 10.
- No. of Pinon Device under programming side:Â 6.
- Connector type on USBASP side:Â Male.
- Connector type on Device under programming side:Â Female.
- Header Pin Pitch: 2.54mm (0.1in).
- Pin Numbers Text: Yes on Top and Bottom sides of every pin.
₹60.00 Excl. GST 18% -
Case for RA169 HIFI DAC+ Sound Card
- High-Quality Acrylic Case.
- Easy To Assemble.
- Has All Cut Outs.
- Provides Protection To DAC As Well As Raspberry Pi.
₹236.00 Excl. GST 18% -
DC 12V 1 Channel Relay Module Infrared IR Remote Switch Control
- DC 12V Home lighting system
- Remote control switch
- Smart Home / Home Automation
- Garage Door
- Remote controlled gates
- Security Monitoring
- LED lighting
- Fluorescent lamp
₹295.00 Excl. GST 18% -
DC 5V 1 Channel Relay Module Infrared IR Remote Switch Control
- DC 5V Home lighting system
- Remote control switch
- Smart Home / Home Automation
- Garage Door
- Remote controlled gates
- Security Monitoring
- LED lighting
- Fluorescent lamp
₹295.00 Excl. GST 18% -
DC12-24V TPA3116D2 2.1 Channel Digital Subwoofer Power Amplifier Board
- Adopts two high-quality TPA3116D2 digital amplifier chips.
- Powered by DC 12-24V, wide input voltage.
- User can adjust the volume by themselves easily.
- Applicable speaker impedance: 4-8 ohm.
- Sound quality is very good, high efficiency and amplifying power.
- 50W x 2+100W Â 2.1 channels(left/right channel and subwoofer channel), high efficiency and low-heat.
₹1,049.00 Excl. GST 18%DC12-24V TPA3116D2 2.1 Channel Digital Subwoofer Power Amplifier Board
₹1,049.00 Excl. GST 18% Add to cart -
₹124.00 Excl. GST 18% -
ESP-01 Adapter 3.3V 5V Board
- On-board level shift circuit.
- Arduino UNO R3 and the compatible board can directly connect to this module.
- Interface logic voltage: 3.3V / 5V compatible(On-board level shift circuit).
- Working voltage: 4.5~5.5V (Onboard 3.3V LDO Regulator).
- Working current: 240mA(MAX).
₹110.00 Excl. GST 18% -
ESP-01 ESP8266 Serial WIFI Wireless Transceiver Module
- 802.11 b/g/n Standards
- Wi-Fi Direct (P2P), soft-AP
- 1MB Flash Memory
- Integrated low power 32-bit CPU could be used as an application processor
- A-MPDU & A-MSDU aggregation & 0.4ms guard interval
- Wake up and transmit packets in < 2ms
- Standby power consumption of < 1.0mW (DTIM3)
₹128.00 Excl. GST 18% -
ESP8266/ ESP-12F Module/ Serial WIFI Witty Cloud Development Board + MINI nodeMCU
- LDR Light Sensor on board.
- WS2812 Led on board.
- Includes CH340G USB-to-UART programmer.
- Includes LDR (light dependent resistor a.k.a photoresistor) connected to ESP’s ADC pin.
- Supports 3 modes: AP, STA, AP+STA.
- Dimensions: 24mm x 16mm.
- Micro USB connection for power and/or programming.
₹399.00 Excl. GST 18%ESP8266/ ESP-12F Module/ Serial WIFI Witty Cloud Development Board + MINI nodeMCU
₹399.00 Excl. GST 18% Add to cart -
GPD2846A TF Card MP3 Decoder Board 2W Amplifier Module
- Working Voltage: 3.7V Lithium Battery 600MA or 5V USB Power Supply
- With Power supply, it can play Automatically
- With Multifunction LED indicator
- Supports MP3 format playback
- Supports USB audio mode
₹95.00 Excl. GST 18% -
GSM SIM800C Modem Shield with Antenna
- Supply Voltage: 3.4V ~ 12V
- GSM: 850, 900, 1800 and 1900MHz
- Flash Memory: 24MB
- RAM Memory: 32MB
₹765.00 Excl. GST 18% -
HC-05 6pin Bluetooth Module with TTL Output
- Bluetooth protocol: Bluetooth Specification v2.0+EDR.
- Modulation: GFSK(Gaussian Frequency Shift Keying).
- Frequency: 2.4GHz ISM band.
- Emission power: =4dBm, Class 2.
- Sensitivity: =-84dBm at 0.1% BER.
₹235.00 Excl. GST 18% -
IR Remote Control without Battery
- Remote control distance: more than 8 meters
- Power Supply: CR2032 Battery
- Pointing Angle: up to 60º
- Crystal: the oscillation frequency of 455
- IR carrier frequency: 38KHz
- Output form: Digital
- Button: free height is less than 3mm, the force 200-350g, the life of more than 200 000 click
₹48.00 Excl. GST 18% -
KCX BT003 Bluetooth 4.2 Stereo Audio Receiver Wireless Module
- Operating Voltage: 3.3-5VDC
- Operating Current: 35mA
- Bluetooth Version: 4.2
- Stereo Channel Output
₹375.00 Excl. GST 18% -
LM358 Gain Amplification Operational Amplifier Module
- LM358 chip onboard.
- 100 gain of the circuit design.
- Onboard power indicator.
- 10K onboard adjustable resistance, you can adjust the magnification.
- The chip has led major pin can be directly input and output signals.
₹73.00 Excl. GST 18% -
Momentary Tactile Push Button Module DC 5V Switch
- Operating Voltage: 5V
- Contact Resistance: 50mΩ max (initial)
- Operating Force: 180/230(±20gf)
- Electrically Life: 100,000 cycles
- I/O pins: 3 pins
- Environment temperature: -25°C to +105°C
- Seal temperature: 250°C-280°C
₹48.00 Excl. GST 18% -
MT8870 DTMF Decoding Telephone Module
- Working voltage: 5V
- Power Consumption: 500mW(MAX)
- On-board voice input interface.
- Onboard 3.5mm input interface.
- On-board LED, it is very convenient to check the output state.
₹107.00 Excl. GST 18% -
MXD1230 12mm 5mW Red Point Laser Module Point Spot Size Adjustable Laser
- Laser Output Type: Red Point Laser
- Weight: 15gm
- Wavelength: 650nm
- Voltage: 3~6V
- Output Power: Min 2.5mW, Typical 3.0mW, Max 5.0mW
- Focus point Intensity can be adjusted with help of lens ring head
₹195.00 Excl. GST 18%MXD1230 12mm 5mW Red Point Laser Module Point Spot Size Adjustable Laser
₹195.00 Excl. GST 18% Add to cart -
MXD1230 6mm 650nm 5mW Red Line Laser Module
- Laser Output Type:Â Red LINEÂ Laser
- Weight: 15gm
- Wavelength: 650nm
- Voltage: 3~6V
- Output Power: Min 2.5mW, Typical 3.0mW, Max 5.0mW
- Working current: Min 10mA, Typical 20mA, Max 25mA
- Working voltage: Min 2.3VDC, Typical 4.5VDC, Max 8.0VDC
₹195.00 Excl. GST 18% -
NodeMcu ESP8266 V3 Lua CH340 Wifi Development Board
- Power input: 4.5V ~ 9V (10VMAX), USB-powered
- Transfer rate: 110-460800bps
- Drive Type: Dual high-power H-bridge
- Don’t need to download resetting
- A great set of tools to develop ESP8266
- Support UART / GPIO data communication interface
- Support Smart Link Smart Networking
- Working temperature: -40°C ~ +125°C
- Flash size: 4MByte
- Lowest cost WI-FI
₹225.00 Excl. GST 18% -
Non-Destructive MP3 Decoding Board with Self-Powered TF Card U Disk Decoded Player Module
- Support MP3 format, playing power on automatically.
- When mp3 is played the red LED flashes.
- Press menu button enter the single / all song play mode.
- Support U disk (test 32G), TF Card (test 16G) play mode;Â power on default.
- Buttons can be adjusted up and down to control songs, volume up and down, pause or play, mode switching.
₹160.00 Excl. GST 18% -
PAM8403 5V 2-channel Stereo 3W+3W Audio Amplifier
- Dual channel stereo, high output power (3w + 3w power 5V and 4 ohms load)..
- 3W Output at 10% THD with a 4ΩLoad and 5V Power Supply.
- Filterless, Low Quiescent Current and Low EMI and Low Noise.
- Double panel wiring solves crosstalk.
- Super mini design allows it to be easily placed in a variety of digital products.
- Short Circuit Protection and Thermal Shutdown
₹30.00 Excl. GST 18% -
PAM8403 Mini Digital Power Amplifiers 3W Dual Track Red
- Input Voltage : 2.5V-5.5V (USB power supply).
- Output Impedance : 4 ohm.
- Efficiency : 90%.
- Frequency Response : 150Hz – 20KHz.
- Input Impedance : 2K ohm.
- Dimensions : 15 x 20mm.
₹54.00 Excl. GST 18% -
₹130.00 Excl. GST 18%PAM8406 Digital Amplifier Module With Volume Control Potentiometer 5Wx2 Stereo
₹130.00 Excl. GST 18% Add to cart
