2S 5A 8.4V 18650 Lithium Battery Charger Board Protection Module has the main IC using original precision imported components. With overcharge, over-discharge, over current, short circuit protection function, for a variety of different shapes of 3.7V capacity lithium batteries. Using the Japanese precision protection IC, VISHAY, AOS, IR, and other high-quality MOSFET, an FR-4 low-temperature coefficient of the plate, well-designed, comprehensive test. Compact size, suitable for many requirements of high integration, low-cost occasions, can meet the performance requirements of many aspects, to ensure the absolute safety of the battery group.

Protections:

1. Short circuit protection.
2. Overcharge protection.
3. Over-discharge protection.
4. Over-current protection.

Connections:

MB: The Common connection point between the batteries.

B+ : Battery V+ Positive
B- : Battery V- Negative
P+ : Charging V+
P- : Charging V-

Features:

• Maximum Working Current: 5A
• Transient Current: 7A
• Operating Temperature: -40°C-50°C
• Internal Resistance: Less than 45m
• B+ B-: The interface of battery core
• P+ P-: The connector of the battery board

Specifications:

Package Includes:

1 x 2S 5A 8.4V 18650 Lithium Battery Charger Board Protection Module

*Product Images are shown for illustrative purposes only and may differ from actual product.
