74HC86 Quad 2-Input EXOR Gate IC (7486 IC) DIP-14 Package

16.00 Excl. GST 18%

In stock

  1. IC Name: 74HC86
  2. Type: Quad
  3. Material: Plastic
  4. Package/Case: DIP-14
Compare
SKU: RC-5531 Category: Tags: , ,


✔ Shipping Charge Only Rs.49

✔ Free Delivery on all Orders Above Rs.999

✔ All Orders Shipped within 24 Hours

✔ GST Input Tax Credit is available


The 74HC86 exclusive OR gate utilizes advanced silicon-gate CMOS technology to achieve operating speeds similar to equivalent LS-TTL gates while maintaining the low power consumption and high noise immunity characteritic of standard CMOS integrated circuits. These gates are fully buffered and have a fanout of 10 LS-TTL loads. The 74HC logic family is functionally as well as pin out compatible with the standard 74LS logic family. All inputs are protected from damage due to static discharge by internal diode clamps to Vcc and ground.

Note: For Technical Specifications about the IC go through the Datasheet in the Attachment.

Features:

  • Four Independent EXCLUSIVE-OR Gates
  • Standard Pin Arrangement
  • Fast Switching Times
  • Operating Temperature up to 70oC
  • High-Speed CMOS Type

Package Includes:

1 x 74HC86 Quad 2-Input EXOR Gate IC (7486 IC) DIP-14 Package

Datasheet: Click Here


*Product Images are shown for illustrative purposes only and may differ from actual product.


Weight 0.01 kg
Dimensions 2 × 1 × 1 cm
