2N6027 Programmable Unijunction Transistor TO-92 Package
₹26.00 Excl. GST 18%
- Type: Unijunction
- Anode-Cathode Volt (Vak): ±40V
- Gate-Cathode Forward Volt (Vgkf): 40V
- DC Forward Anode Current (It): 0.15A
- DC Gate Current (Ig): ±50mA
- Power Dissipation (Ptot): 300mW
✔ Shipping Charge Only Rs.49
✔ Free Delivery on all Orders Above Rs.999
✔ All Orders Shipped within 24 Hours
✔ GST Input Tax Credit is available
2N6027 is Designed to enable the engineer to “program’’ unijunction characteristics such as RBB, IV and IP by merely selecting two resistor values. Application includes thyristor−trigger, oscillator, pulse and timing circuits. These devices may also be used in special thyristor applications due to the availability of an anode gate. Supplied in an inexpensive TO−92 plastic package for high−volume requirements, this package is readily adaptable for use in automatic insertion equipment.
Features:
- Advanced process technology
- Low error voltage
- Fast switching speed
- Full-voltage operation
- High power and current handling capability
Specifications:
| Type | Unijunction |
| Gate to Cathode Forward Voltage (VGKF) | 40V |
| Gate to Cathode Reverse Voltage (VGKR) | 5V |
| Gate to Anode Reverse Voltage (VGAR) | 40V |
| Anode to Cathode Voltage (VAK) | 40V |
| Offset Voltage (VT) | 1.6V |
| DC Forward Anode Current (IT) | 150mA |
| DC Gate Current (IG) | 50mA |
| Non−Repetitive Peak Forward Current (ITSM) | 5A |
| Operating Temperature Range | -50 to 100°C |
| Power Dissipation (PD) | 300mW |
Package Includes:
1 x 2N6027 Programmable Unijunction Transistor TO-92 Package.
.
